Fume Hood

To protect lab environment and operators during general chemical applications.

A chemical fume hood (fume cupboard) is a specific type of air ventilation system equipped with powerful and energy-efficient fans and high-quality filtration media. This hood primarily functions to enact as a safety engineering control and provide protection from fumes, particulate, and dust against personnel. Secondarily, these fume hoods are built to protect users from application hazards such as fires, chemical spills, and adverse reactions.

Product Classification

Lab1st provide both ducted and recirculating (ductless) fume hoods. The principle is the same for both types: air is drawn in from the front (open) side of the cabinet, and either expelled outside the building or made safe through filtration and fed back into the room.

Ducted Fume Hood

Ducted Fume Hood should connect to a remote exhaust system to safely ventilate outside the building. It employ multiple filters (optional) and a strong fan. It’s suitable when there’s a potential for being exposed to high volumes of particulate and toxic fumes.

Ductless Fume Hoods

Ductless fume hoods capture and remove contaminants and send clean, filtered air back into the lab without the need for external venting. Its air filtration systems are designed to keep harmful airborne contaminants away from the operator's respiratory zone while they work within the hood.

All Lab1st fume hoods are equipped with microprocessor control system, LED display, memory function in case of power-failure and LED lamp for illumination.



They all meet the international safe standards for face volecity 0.3~0.8m/s.



To meet different needs and requirements, below seven series for your choices

LFH Series (Ducted, benchtop)
Available: 25"

​

  • Folding acrylic front window, down part with free stop function.

  • Built-in centrifugal blower

  • Interlock function: UV lamp and blower, LED lamp. (Only for choosing UV lamp).

  • Note: Experiments with strong acids and alkali, flammable  or explosive substances cannot be conducted with this type fume hood.

组 6.png

LFH-E Series (Ducted, economical)
Available: 31", 39", 51", 63"

​

  • Adjustable air speed: 9 levels.

  • Resistant to moderate acid and alkali.

  • Manual front glass window, height adjustable.

  • Built-in PP centrifugal blower; low noise, easy installation.

组 5.png

LFH-A Series (Ducted, vertical)
Available: 32", 40", 52", 64"

​

  • UV lamp for sterilization.

  • Resistant to weak acid and alkali.

  • Adjustable air speed: 9 levels.

组 4.png

LFH-P Series (Ducted, Porcelain white PP)
Available: 31", 39", 51", 62"

​

  • It is safer to use anti-corrosive water tap.

  • Microprocessor control system, LED display.

  • With memory function in case of power-failure.

  • Made of porcelain white PP, resistant to acid, alkali and anti-corrosion.

  • Front window which is made of 5mm thick transparent toughened glass maximize light and visibility inside the fume hood, providing a bright and open working environment.

组 3.png

LFH-X Series (Ducted, slope)
Available: 35", 43", 54", 66"

​

  • UV lamp for sterilization.

  • Resistant to weak acid and alkali.

  • Adjustable air speed: 9 levels.

  • Alarm when filter working time 3500 hours.

  • Back side air compensation, to avoid turbulence in work area.

  • 8°slope front ergonomics design, fatigue-free working posture.

  • Transparent side glass windows

组 3.png

LFH-X Series (Ducted, slope)
Available: 35", 43", 54", 66"

​

  • UV lamp for sterilization.

  • Resistant to weak acid and alkali.

  • Adjustable air speed: 9 levels.

  • Alarm when filter working time 3500 hours.

  • Back side air compensation, to avoid turbulence in work area.

  • 8°slope front ergonomics design, fatigue-free working posture.

  • Transparent side glass windows

组 2.png

LFH-C Series (Ductless)
Available: 36", 44", 56", 67"

​

  • 8°slope front ergonomics design, fatigue-free working posture.

  • Temperature and humidity sensors.

  • Three side transparent Acrylic windows, front window reversal design.

  • Double-layers structure: 1mm sheet metal surface; Chemical resistant phenolic resin work table.

  • Electronic control system, anti-overload, anti-electric shock, stable performance, long service life.

  • Inside and outside probe, detect indoor air pollution and filter conditions. Audible and visual alarm for changing filter.

LFH Series (Ducted, benchtop)
Available: 25"

​

  • Folding acrylic front window, down part with free stop function.

  • Built-in centrifugal blower

  • Interlock function: UV lamp and blower, LED lamp. (Only for choosing UV lamp).

  • Note: Experiments with strong acids and alkali, flammable  or explosive substances cannot be conducted with this type fume hood.

组 6.png

LFH-E Series (Ducted, economical)
Available: 31", 39", 51", 63"

​

  • Adjustable air speed: 9 levels.

  • Resistant to moderate acid and alkali.

  • Manual front glass window, height adjustable.

  • Built-in PP centrifugal blower; low noise, easy installation.

组 5.png

LFH-A Series (Ducted, vertical)
Available: 32", 40", 52", 64"

​

  • UV lamp for sterilization.

  • Resistant to weak acid and alkali.

  • Adjustable air speed: 9 levels.

组 4.png

LFH-P Series (Ducted, Porcelain white PP)
Available: 31", 39", 51", 62"

​

  • It is safer to use anti-corrosive water tap.

  • Microprocessor control system, LED display.

  • With memory function in case of power-failure.

  • Made of porcelain white PP, resistant to acid, alkali and anti-corrosion.

  • Front window which is made of 5mm thick transparent toughened glass maximize light and visibility inside the fume hood, providing a bright and open working environment.

组 3.png

LFH-X Series (Ducted, slope)
Available: 35", 43", 54", 66"

​

  • UV lamp for sterilization.

  • Resistant to weak acid and alkali.

  • Adjustable air speed: 9 levels.

  • Alarm when filter working time 3500 hours.

  • Back side air compensation, to avoid turbulence in work area.

  • 8°slope front ergonomics design, fatigue-free working posture.

  • Transparent side glass windows

组 2.png

LFH-C Series (Ductless)
Available: 36", 44", 56", 67"

​

  • 8°slope front ergonomics design, fatigue-free working posture.

  • Temperature and humidity sensors.

  • Three side transparent Acrylic windows, front window reversal design.

  • Double-layers structure: 1mm sheet metal surface; Chemical resistant phenolic resin work table.

  • Electronic control system, anti-overload, anti-electric shock, stable performance, long service life.

  • Inside and outside probe, detect indoor air pollution and filter conditions. Audible and visual alarm for changing filter.

组 1.png

LFH-W Series (Work-in)
Available: 39", 50", 62"

​

  • With memory function in case of power-failure.

  • Operators are available to walk into the fume hood to operate if need.

  • Large room exhaust system, suitable for large laboratory instruments and equipment.

How to chooce a fume hood for your laboratory?
​Choosing the right chemical fume hood is essential to ensure safety from hazardous chemicals and vapors in your lab. Here are important questions and considerations to help you choose the right hood.



  • Application: What kind of work do you do inside your hood?

  • Work area required: What size lab hood do you need?

  • What are the installation and operating costs of the hood?

Product Series
Features
Internal Width
External Width
Max. Opening
Air Velocity
Front Window
Alarm
Resistance to
Filter
LFH
Benchtop
25"
27.6”
26"
0.3-0.8m/s
Manual
Filter
Weak acid and alkali
Standard active carbon filter or optional HEPA filter
LFH-E
Economical
31", 39", 51", 63"
39“, 47", 59", 71"
29.5"
0.3-0.8m/s
Manual
None
Moderate acid and alkali
Not optional
LFH-A
Vertical front design
32", 40", 52", 64"
41", 49", 61", 73"
20.5"
0.3-0.8m/s
Motorized
Filter
Weak acid and alkali
Optional active carbon filter or HEPA filter
LFH-P
Porcelain white PP
31", 39", 51", 62"
41", 49", 61", 73"
29"
0.3-0.8m/s
Manual
None
Strong acid and alkali
Optional active carbon filter
LFH-X
Slop front ergonomics
35", 43", 54", 66"
39", 47", 59", 71"
20.5"
0.3-0.8m/s
Motorized
Filter
Weak acid and alkali
Standard active carbon filter or optional HEPA filter
LFH-C
Ductless
36", 44", 56", 67"
39", 47", 59", 71"
25.6"
0.4-0.6m/s
Manual
Air volecity, filter, voc
Weak acid and alkali
Chemical filter or optional HEPA filter
LFH-W
Walk in
39", 50", 62"
47", 59", 71"
51"
0.3-0.8m/s
Manual
None
Weak acid and alkali
Not optional
